| Specification |
| Model |
usb-2450-30 |
| Standard |
IEEE 802.11b/g |
| Antenna Gain |
5dbi |
| Frequency Range |
2.400GHz~2.484GHz |
| Number of operation channel |
2.412~2.462GHz(Canada, FCC) / 11Channels |
| 2.412~2.484GHz(Japan, TELEC) / 14 Channels |
| 2.412~2.472GHz(Euro, ETSI) / 13 Channels |
| Security |
64/128bit WEP |
| WPA(TKIP with IEEE 802.1x) |
| WPA2(AES with IEEE 802.1x) |
| Access Protocol |
CSMA/CA |
| RF Output Power(Typical) |
802.11b: up to 30 ± 1 dBm |
| 802.11g: up to 24 ± 1 dBm |
| Data Rate |
802.11g: 54, 48, 36, 24, 18, 12, 9 & 6Mbps |
| 802.11b: 11, 5.5, 2 and 1 Mbps with auto-rate fall back |
| Sensitivity: |
-73dBm @ 54Mbps |
| -85dBm @ 11Mbps |
| Interface |
mini USB |
| Operating Temperature |
0~60J ambient temperature |
| Storage Temperature |
-20~70J ambient temperature |
| Operation Voltage |
5V |
| Storage Humidity |
10H ~ 90H (Non-condensing) |
| Driver support |
Windows® 2000, XP 32/64, Vista 32/64 |
| Verification of compliance |
RoHSBCE |
| Size |
L99 x W60 x H16 mm |
| Weight |
167.5g |
