TECHNICAL SPECIFICATION

 CABLE TYPE

RF-240 COAXIAL CABLE

 STRUCTURE

 Composition(No./mm)

1/ 1.42mm

Conductor

 Material

Bare Copper Wire

 Outside Diameter (mm)

1.42± 0.03mm

 Material

Gas Injected Foamed Polyethylene

Insulation

 Thickness (mm)

1.20mm

 Nom. Diameter(mm)

3.81± 0.1mm

Shield

 Material

(1) Double Side Bonded AF

(2) Tinned Copper Wire

 Construction

0.050mm

16*8/ 0.12mm

 Picks/inch

90%

 Diameter(mm)

0.12± 0.008mm

 Material

PVC

Jacket

 Diameter(mm)

6.1± 0.15mm

 Color

Black

Printing

 ELECTRICAL CHARACTERISTIC

 Impedance

W

50 ± 3

 Insulation Resistance

MW / km

1000 ↑

 Capacitance

pF/M

75± 3

 Attenuation

Frequency(MHz)

30

150

450

900

1500

1800

2500

dB/ 100M

7.9

8.1

17.1

24

33.8

37.8

45.6

DRWN.

Grace Hsu

DRWN. No.:

CHKD.

C.H. Liu

APPD.

Vincent Shen

Date:APR.10, 2003
